Three chucks can be reversed for cutting, and are applied to a variety of clamping and cutting modes can be used to achieve zero-tail cutting of tubes, improve tube utilization, and save costs.
Products
EP Bevel Cuts Laser Big Pipe Cut Automatic Loading and Unloading Three Chuck FiberLaser Tube Cutting Machine
Introducing the Raydafon EP Bevel Cuts Laser Big Pipe Cut Automatic Loading and Unloading Three Chuck Fiber Laser Tube Cutting Machine, a state-of-the-art solution designed for precision and efficiency in metal fabrication. This cutting-edge machine is engineered to deliver flawless bevel cuts on large pipes, automating the loading and unloading process for unparalleled productivity. Its advanced fiber laser technology ensures high-speed, clean cuts with minimal material waste, making it an indispensable tool for industries requiring meticulous metalwork. The three-chuck system provides exceptional stability and precision, catering to a wide range of pipe diameters and thicknesses. Ideal for manufacturers, metalworkers, and fabrication shops, the Raydafon EP transforms complex cutting tasks into simple, efficient operations. Experience the difference with a machine that not only meets but exceeds expectations, offering a seamless blend of innovation, reliability, and performance. Whether for industrial applications or specialized projects, this machine stands out for its ability to handle demanding tasks with ease, ensuring your operations are smoother, faster, and more cost-effective. Choose Raydafon EP for a cutting solution that brings precision, efficiency, and innovation to your workshop.
Round tube diameter range 15-450mm(change according to the size of the chuck), can support multiple tube type cutting, channel,angle, I-beam, etc.; can achieve ultra-long tube cutting, 12 meters loading 12 meters downfeed (expandable) standard semi-automatic loading, more efficient, convenient and stable
Optional 45° bevel, real 0 tailing and 100% material utilization
Fit for engineering machinery, bridge & tunnel, construction machinery, steelwork industry, etc.
Fit for engineering machinery, bridge & tunnel, construction machinery, steelwork industry, etc.
Product Name | Three Chuck Laser Pipe Cutting Machine |
Maximum Cut Pipe Length | Cutting Length From 7000 To 12000 mm |
Cut Pipe Diameter | 15~450mm (Circle Of Workpiece) |
Pipe Thickness | Depends On The Power |
Cutting Accuracy | ±0.1mm |
X, Y axis positioning accuracy | ±0.05/1000mm |
X, Y axis repeat positioning accuracy | ±0.03/1000mm |
Acceleration | 0.8G m/s² |
Maximum Operating Speed | 60 m/min |
Maximum Weight For Each Tube | 500Kg |
Chuck Rated Speed | 60rpm |
Mainframe Shape | About 22000×6000×2500mm |
Laser power | 8000W Or Customized As Required |
Three Chunks
Fully enclosed pneumatic chuck
---Effectively prevent cutting dust pollution
---Full stroke design, high alignment accuracy
---Gear transmission, good rigidity, high transmission precision
---The front chuck and the middle chuck are installed face to face, helping to achieve zero tailing
The four-jaw guide rail is driven by the guide rail mechanism, which makes the four-jaw straightness and stability higher, and truly achieves the effect of self-centering
Customizable Chain Type Loading And Unloading Device
The chain type loading and unloading device can realize the handlingand lifting of the upper material of the pipe as well as the receiving ofthe lower material side and the transportation of the finished parts
The Servo Follow-up Support System
The automatic centering device can automatically center the delivered pipe so that the chuck can hold the pipe accurately
Bus control system
The rich process database is easy to operate and powerful, and can be deeply developed for different customer needs.
CHOOSE YOUR LASERTUBE
Make Your Choice
Lasertube systems are our 2D and 3D laser cutting systems for tubes, bars and profiles, from 15 mm to 350 mm in diameter and up to 12000 mm in length.
Q: Do you have CE document and other documents for customs clearance?A: Yes, we have CE, Provide you with a one-stop service.At first we will show you and and after shipment we will give you CE/Packing list/Commercial Invoice/ Sales contract for customs clearance.
Q: Why the machine price not include fiber source?A:Different customers, different requirements, and many different laser power can be optional, that's why we list the price not include fiber source parts.
Q: If we are interested in your machine, how to choose proper power?A:Please tell us the following answer, our professional seller will recommend you proper power.
1. What material you want to cut,stainless steel,carbon steel or other?
2. What thickness do you want to cut?
Q:How can I do if the laser cutting machine goes wrong?A: If confronted with such problems, please contact us asap and do not try
fix the machine by yourself or someone else. We will response within 24 hours as quick as we can to solve it for you.
Q: How about warranty?A: 3 years quality guaranty, the machine with main parts(excluding the consumables) shall be changed free of charge(some parts will be maintained) when if any problem during the warranty period.
Q: Do you have after sales support?A: Yes, we are happy to give advice and we also have skilled technicians available across the world, We need your machines running in order to keep your business running
