5:1 Planetary Gearbox Nema 17 Stepper Motor 1.68A for DIY CNC Robot 3D Printer

Discover the power and precision of the Raydafon 5:1 Planetary Gearbox Nema 17 Stepper Motor, your ultimate companion for DIY CNC, robotics, and 3D printing projects. Designed for enthusiasts and professionals alike, this motor combines high torque (1.68A) with a compact planetary gearbox ratio of 5:1, ensuring smooth, efficient, and reliable performance for your creative endeavors. What sets the Raydafon Stepper Motor apart? Its robust construction and advanced engineering deliver unparalleled durability and precision, making it the go-to choice for demanding applications. Whether you're building a CNC machine, a custom robot, or enhancing your 3D printer, this motor provides the perfect balance of speed and torque, enabling you to bring your ideas to life with ease. Ideal for makers, hobbyists, and tech enthusiasts, the Raydafon Stepper Motor is not just a tool—it's a gateway to innovation. Experience the satisfaction of flawless operation and the joy of creating without limits. With its superior performance and reliability, it stands out from the competition, offering you a hassle-free solution to complex mechanical challenges. Embrace the future of DIY projects with the Raydafon 5:1 Planetary Gearbox Nema 17 Stepper Motor. Your creations deserve the best—make it happen with Raydafon.

Send Inquiry

Product Description

This is popular geared Nema 17 stepper motor with a medium body and torque. It has an integrated planetary gearbox with a 5.18:1 gear ratio, the resolution reach 0.35°step angle. It's a good solution in applications that need very low rotation speeds and/or lots of torque.

Electrical Specification

* Manufacturer Part Number: 17HS15-1684S-PG5
* Motor Type: Bipolar Stepper
* Step Angle: 0.35°
* Holding Torque: 1.68Nm
* Rated Current/phase: 1.68A
* Phase Resistance: 1.65ohms
* Recommended Voltage: 12-24V
* Inductance : 3.2mH±20%(1KHz)

Gearbox Specifications

* Gearbox Type: Planetary
* Gear Ratio : 5.18:1
* Efficiency: 90%
* Backlash at No-load : <=1°
* Max.Permissible Torque: 2Nm(283oz-in)
* Moment Permissible Torque: 4Nm(566oz-in)
* Shaft Maximum Axial Load: 50N
* Shaft Maximum Radial Load : 100N

Physical Specifications
* Frame Size: 42 x 42mm
* Motor Length: 40mm
* Gearbox Length: 27.3mm
* Shaft Diameter: 8mm
* Shaft Length: 20mm
* D-cut Length: 15mm
* Number of Leads: 4
* Lead Length: 500mm
* Weight : 460g

Connection:

Black(A+), Green(A-), Red(B+), Blue(B-)

Warning:

Make sure the motor connect to a constant current or chopper drive controller before you test motor.
Connecting the motor directly to a power supply will destroy the motor.
